Supported cameras
Interchangeable lens format cameras with multi accessory ports
-
Guide Number
18 m/59 ft. (at ISO 100) with wide panel 10 m/33 ft. (at ISO 100)
-
Electronic Construction
Automatic Insulated Gate Bipolar Transistor (IGBT) and series circuitry
-
Flash Exposure Control
Options available using camera controls:
Flash mode: Fill flash (Front-curtain sync)
Front-curtain Slow-sync
Rear-curtain sync
Rear-curtain Slow-sync
Flash compensation
-
Effective flash range (i-TTL)
2 to 66 ft. (0.6 to 20 m) (varies with ISO sensitivity, bounce angle, and aperture)
-
Bounce Function (Rotate)
Flash head tilts up to 120° with click-stops at 0°, 60°, 75°, 90°, 120° (without lock mechanism)
-
Flash Duration
1/1400 sec. when fired at full power
-
Power ON/OFF
Turn the flash on and off using the ON/OFF switch.
-
Flash-ready Indicator
Lights up: recycled and ready to fire.
Warning indicator: Blinks (see the camera Reference Manual for more information)
-
Supported Flash Modes
i-TTL
Manual flash
-
Other Functions
Thermal cut-out
Firmware update
-
Approx. Dimensions (Width x Height x Depth)
2.3 in. (57.4 mm) x 2.7 in. (68.4 mm) x 2.5 in. (62.3 mm)
-
Approx. Weight (without batteries)
3.2 oz. (92 g)
-
Supplied Accessories
- BS-N2000 Mounting Foot Cover
- SW-N7 Wide Panel
- SS-DC1 Polyester Soft Case
