Lens Mount
Nikon F bayonet mount
-
Picture Angle
Nikon DX format (Effective picture angle 1.5x [Approx.] conversion factor)
-
Effective Pixels
4.1 million
-
Sensor Size
23.3mm x 15.5mm
-
Image Sensor Format
DX
-
Image Area (pixels)
DX-format
(L) 2,464 x 1,632
(M) 1,840 x 1,224
High Speed Crop
(L)3,216 x 2,136
(M) 2,400 x 1,600
(S) 1,600 x 1,064
-
File Format Still Images
Compressed 12-bit NEF (RAW)
DPOF (Uncompressed TIFF-RGB or Compressed JPEG)
Exif 2.21, Compliant DCF 2.0
Uncompressed 12-bit NEF (RAW)
-
Storage Media
CompactFlash© (CF) (Type I/II, compliant with UDMA)
MicroDrive©
-
Card Slot
1 CompactFlash© (CF) card
-
Viewfinder
Built-in Diopter adjustment (-3 to +1m⁻¹)
Eyepiece Shutter Provided
Frame Coverage: approx 100%
Magnification: Approx. 0.86x with 50mm f/1.4 lens set to infinity and -1.0m⁻¹
Optical-type Fixed Eye-Level Pentaprism
-
Viewfinder Frame Coverage
100% Approx.
-
Viewfinder Magnification
0.86x Approx.
-
Viewfinder Eyepoint
19.9mm (-1.0m¯¹)
-
Focusing Screen
B-type BriteView Clear Matte Screen III; Interchangeable with Optional E-type Screen with Grid Lines
-
Reflex Mirror
Instant-return type
-
Lens Aperture
Instant-return type with depth-of-field preview button
-
Depth-of-field Control
Yes
-
Lens Compatibility at a Glance***
AF-S or AF lenses fully compatible
Metering with AI lenses
-
Compatible Lenses
AF NIKKOR (including AF-S, DX, VR and D-/G-type) : All Functions Supported
AF NIKKOR other than D-/G-type: All Functions Supported Except 3D Color Matrix Metering and 3D Multi-Sensor Balanced Fill-Flash
AI-P NIKKOR: All Functions Supported Except 3D Color Matrix Metering, 3D Multi-Sensor Balanced Fill-Flash and AF Supported
D-type Manual-Focus NIKKOR: All Functions Supported Except Autofocus
Non-CPU AI NIKKOR: Usable in A or M mode with Matrix, Center-Weighted and Spot metering. Indication of Aperture No., after user inputs the aperture f/No. and focal length by multi-selector. Non-CPU: Can be used in mode M, but Exposure Meter does not Function; Electronic Rangefinder can be used if Maximum Aperture is f/5.6 or Faster
-
Shutter type
Charge-coupled electronic and mechanical shutter; 30 to 1/16,000 sec. and Bulb
-
Fastest Shutter Speed
1/8000 sec.1/3
1/2
1
-
Slowest Shutter Speed
30 sec.1/3
1/2
1
-
Top Continuous Shooting Speed at full resolution
9 frames per second
-
Self-timer
2, 5, 10, 20 sec. Timer duration electronically controlled
-
Exposure Metering System
D-/G-type Nikkor lenses support 3D Color Matrix Metering using the 1,005-pixel CCD while other AF Nikkor lenses with built-in CPUs support Matrix Metering (Non-CPU lenses require manual input of lens data)
Center-Weighted Metering (75% of the meter's sensitivity concentrated on the 8mm dia. circle)
Spot Metering (4mm dia. circle, approx. 2% of entire frame)
TTL full-aperture exposure metering system
-
Exposure Meter Coupling
CPU
AI
-
Exposure Modes
Aperture-Priority Auto (A)
Manual (M)
Programmed Auto with flexible Program (P)
Shutter-Priority Auto (S)
-
Shooting Modes
Playback mode: playback, menu setting
PC mode: data transfer via personal computer
Continuous high shooting [CH] mode: 8 frames per second (fps) [up to 40 (JPEG) / 25 (RAW:NEF) consecutive shots]
Continuous low shooting [CL] mode: 1 to 7 fps (selectable from menus)
Mirror up mode: first press: mirror up, second press: release
Interval timer (Intervalometer) mode provided
Self-timer mode: time duration can be set
-
Exposure Compensation
±5 EV in increments of 1/3, 1/2 or 1 EV in increments of 1/3
1/2
1
-
Exposure Bracketing
2 to 9 frames in steps of 1/3, 1/2, 2/3 or 1 EV
-
Exposure Lock
Luminosity locked at detected value with AE-L/AF-L button
-
Mirror Lock Up
Yes
-
ISO Sensitivity
ISO 200 - 1600
-
Lowest Standard ISO Sensitivity
2001/3
1/2
1
-
Highest Standard ISO Sensitivity
16001/3
1/2
1
-
Expanded ISO Sensitivity Options
Sensitivity can be extended by 1 or 2 steps beyond ISO 1,600
-
Long Exposure Noise Reduction
Yes
-
Dynamic AF Mode
Dynamic-area AF (supports closest subject priority)
-
Auto-area AF Mode
Yes
-
Autofocus System
Detection range: EV -1 to EV +19 (ISO 100 equivalent, at normal temperature: 20°C/68°F)
Nikon CAM2000 autofocus module
-
Focus Lock
Focus is locked by pressing AE-L/AF-L button or lightly pressing shutter release button in (S) AF
-
Focus Modes
Closest Subject Priority Dynamic AF
Dynamic AF with Focus Tracking and Lock-on(™)
Group Dynamic AF
Manual
Single Area AF
-
Maximum Autofocus Areas/Points
11
-
Flash Control
SB-26: Auto, Manual, Rear Curtain, Repeating Flash, Red Eye Reduction
SB-27: Non-TTL Auto, M, Rear Curtain Sync
SB-28: Auto, Manual, Rear Curtain, Repeating Flash, Red Eye Reduction
SB-28DX: D-TTL, Auto, Manual, Rear Curtain, Repeating Flash, Red Eye Reduction
SB-80DX: D-TTL, Auto Aperture(AA), Auto, Manual, Rear Curtain, Repeating Flash, Red Eye Reduction
SB-400: i-TTL, AA camera option, no Manual output option
SB-600: i-TTL, Manual, Red-Eye Reduction, AF Assist for multi area AF, Auto Zoom, Rear Curtain
SB-800: i-TTL, Auto Aperture (AA), Non-TTL Auto (A), GN, Manual, Rear Curtain, RPT, Red-Eye Reduction, FV Lock, AF Assist for multi-area AF, Zoom
SB-900: CLS cameras: i-TTL, AA, Non-TTL Auto, GN, M, RPT, AutoFP High Speed Sync (D3-series, D2-series, D700, D300s, D300, D200, D80 only), FV Lock, AF-Assist for mulit-area AF, Flash Color Info. Comm., Rear Curtain Sync, Red-Eye Reduction, Auto Zoom
SB-R1/SB-R200 triggered by camera's built in flash: No built in flash
SB-R1C1/SB-R200 triggered by SU-800: i-TTL, M, AutoFP High Speed Sync, Rear Curtain Sync, Slow Sync
SB-50DX: D-TTL, Manual, Rear Curtain
SB-24: Auto, Manual, Rear Curtain, Repeating Flash
SB-25: Auto, Manual, Rear Curtain, Repeating Flash
SB-30: Auto, Manual, Rear Curtain
SB-20, SB-16B, SB-15: Auto, Manual, Rear Curtain
SB-29s: Manual, Rear Curtain
SB-23: Manual, Rear Curtain
SB-22s: Auto, Manual, Rear Curtain
-
Flash Sync Modes
Front-curtain sync (normal)
Rear-curtain sync
Red-Eye reduction
Red-Eye reduction with slow sync
Slow sync
-
Accessory Shoe
Yes
-
Nikon Creative Lighting System (CLS)
CLS Supported
-
White Balance
Auto
Color temperature setting in Kelvin
Manual
Preset
White Balance Bracketing
-
White Balance Bracketing
2 to 9 exposures
-
Monitor Size
2.5 in. diagonal
-
Monitor Resolution
211,200 Dots
-
Monitor Type
TFT-LCD
-
Playback Functions
Full Frame
Highlight Point Display
Histogram Display
Slideshow
Thumbnail (4 or 9 segments)
Zoom
-
Interface
802.11b
NTSC
PAL
USB 2.0 (Hi-Speed)
-
Wi-Fi Functionality
WT-1A
-
GPS
GP-1 GPS unit
-
Total custom Settings
41
-
Battery / Batteries
EN-EL4 Lithium-ion Battery
EN-EL4a Lithium-ion Battery
-
AC Adapter
EH-6 AC Adapter
-
Battery Charger
MH-21 Quick Charger
-
Approx. Dimensions (Width x Height x Depth)
6.2 in. (157.5 mm) x 5.9 in. (149.5 mm) x 3.4 in. (85.5 mm)
-
Approx. Weight
38.4 oz. (1,070 g)
camera body only
-
Optional Accessories
EH-6 AC Adapter
DK-16A Anti-fog Finder Eyepiece
DK-16C Eyepiece Correction Lens
Type E Focusing Screen
CompactFlash™ Card
Nikon Capture 4 software
WT-1A Wireless Transmitter
WA-E1 Extension Antenna
-
Supplied Accessories
- Li-ion Battery EN-EL4
- Quick Charger MH-21
- Body Cap
- Camera Strap AN-D2H
- AV Cable EG-D2
- USB Cable UC-E4
- LCD Monitor Cover BM-3
- Nikon View Software CD-ROM
*Supplied accessories may differ in each country or area
