Type
Single-lens reflex digital camera
-
Lens Mount
Nikon F bayonet mount
-
Effective Pixels
2.66 million
-
Sensor Size
23.7mm x 15.6mm
-
Image Sensor Format
DX
-
Image Sensor Type
CCD
-
Total Pixels
2.7 million
-
Image Area (pixels)
DX-format
(L) 2,000 x 1,312
-
File Format Still Images
Compressed 12-bit NEF (RAW)
JPEG (Baseline Compliant)
TIFF (RGB)
Uncompressed 12-bit NEF (RAW)
-
Storage Media
CompactFlash© (CF) (Type I/II, compliant with UDMA)
-
Card Slot
1 CompactFlash© (CF) card
-
Viewfinder
Optical-type Fixed Eye-Level Pentaprism
-
Viewfinder Frame Coverage
96 % Approx.
-
Viewfinder Magnification
0.80x Approx.
-
Viewfinder Diopter Adjustment
-3 to +1m
-
Lens Compatibility at a Glance***
AF-S or AF lenses fully compatible
Metering with AI lenses
-
Compatible Lenses
3D Color Matrix Metering and 3D Multi-Sensor Balanced Fillflash for D1 Supported
AI-P NIKKOR: All Functions Supported Except 3D Color Matrix Metering, 3D Multi-Sensor Balanced Fill-Flash for D1 and Autofocus Supported
Other type-D NIKKOR lenses: All Functions Supported Except Autofocus
Other AF NIKKOR lenses (excluding F3AF): All Functions Supported
Other Lenses can be used in Aperture-Priority or Manual Mode with Center-Weighted or Spot Metering; Non-CPU: Can be used in mode M, but Exposure Meter does not Function; Electronic Rangefinder can be used if Maximum Aperture is f/5.6 or Faster
Type-D AF NIKKOR Lenses (excluding IX NIKKOR): All Functions Supported
-
Shutter type
Combined electronic (CCD) and mechanicall shutter
-
Shutter Speed
Bulb
-
Fastest Shutter Speed
1/8000 sec.1/3
1/2
1
-
Slowest Shutter Speed
30 sec.1/3
1/2
1
-
Top Continuous Shooting Speed at full resolution
4.5 frames per second
-
Self-timer
Delay can be specified by user, Timer duration electronically controlled
-
Exposure Metering System
3D Color Matrix Metering with 1,005-pixel CCD
Center-weighted
Spot
TTL full-aperture exposure metering system
-
Metering Range
0 to 20 EV (Matrix or center-weighted metering at ISO 100 equivalent, f/1.4 lens, at 20°C/68°F)
2 to 20 EV (Spot metering at ISO 100 equivalent, f/1.4 lens at 20°C/68°F)
-
Exposure Meter Coupling
CPU
AI
-
Exposure Modes
Aperture-Priority Auto (A)
Manual (M)
Programmed Auto with flexible Program (P)
Shutter-Priority Auto (S)
-
Shooting Modes
Single frame shooting
Continuous shooting approx. 4.5 fps, max 21 consecutive shots
Self-timer mode (delay can be specified by user)
PC data transfer mode
-
Exposure Compensation
±5 EV in increments of 1/3EV
-
Mirror Lock Up
Yes
-
ISO Sensitivity
ISO 100 - 800
-
Lowest Standard ISO Sensitivity
200
-
Highest Standard ISO Sensitivity
1600
-
Dynamic AF Mode
Dynamic-area AF (supports closest subject priority)
-
Autofocus System
Nikon Multi-CAM 1300 autofocus module
TTL phase detection
-
Detection Range
-1 to 19 EV (ISO 100, 68°F/20°C)
-
Focus Modes
Dynamic Area AF
Single Area AF
(supports closest subject priority)
-
Maximum Autofocus Areas/Points
5
-
Flash Sync Modes
Front-curtain sync (normal)
Rear-curtain sync
Red-Eye reduction
Red-Eye reduction with slow sync
Slow sync
-
Accessory Shoe
Yes
-
White Balance
Auto (TTL control with 1,005-pixel CCD)
Preset
Six manual modes adjustable from -3 to +3 in 7 steps
-
Monitor Size
2.0 in. diagonal
-
Monitor Resolution
114,000 Dots
-
Monitor Type
Low temperature polysilicon TFT
-
Playback Functions
Histogram Display
Single-Image
Highlights
-
Interface
10-pin RemoteTerminal
Accessory Hotshoe
Audio/video Connector (NTSC or PAL selectable)
DC in
IEEE1394
Sync Terminal for Optional External Flash
Video Out Connector
-
Battery
Rechargeable
-
Battery / Batteries
EN-4 Ni-MH Battery Pack (7.2V DC)
-
AC Adapter
EH-4 AC Adapter
-
Battery Charger
MH-17/16/15 Quick Charger (12V DC)
-
Approx. Dimensions (Width x Height x Depth)
6.2 in. (157 mm) x 6.1 in. (153 mm) x 3.4 in. (86 mm)
-
Approx. Weight
40 oz. (1100 g)
camera body only
-
Optional Accessories
EN-4 Ni-MH Battery Pack
MH-16 Quick Charger
EH-4 AC Adapter
SC-D1 IEEE1394 cable
DK-15 Anti-fog Finder Eyepiece
CompactFlash™ Card
-
Supplied Accessories
- EN-4 Rechargeable Battery
- MH-16 Quick Charger
- EH-4 AC Adapter
- B Type Focusing Screen
- E Type Focusing Screen
- BM-1 LCD Monitor Cover
- BF-1A Body Cap
